Power Adaptors
1Wide AC input range: 100-240VAC, 50-60Hz
2 Full current
3 Anti-interference function
4 With LED indicator
5High efficiency above 80%
1 . All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
2 . Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3 . Tolerance: includes set up tolerance, line regulation and load regulation.
4 . Line regulation is measured from low line to high line at rated load.
5 . Load regulation is measured from 0% to 100% rated load.
6 . Set up time is measured at cold first start. Turning ON/OFF the power supply very quickly may lead to increase of the set up time.
7 . When the peak load of the unit reaches 150% and delivers for over 1 second, it enters hiccup mode and recovers once rated current lower than 150%.
8 . The ambient temperature derating of 5℃/1000m is needed for operating altitude greater than 2000m(6500G).
|
MODEL |
FS-12D2000-A |
|
|
Output |
DC VOLTAGE |
12V |
|
RATED CURRENT |
2A |
|
|
CURRENT RANGE |
0-2A |
|
|
RATED POWER |
24W |
|
|
VOLTAGE TOLERANCE（Note4） |
±5.0% |
|
|
LINE REGULATION（Note3） |
±0.5% |
|
|
LOAD REGULATION（Note5） |
±1% |
|
|
RIPPLE&NOISE（Note2） |
≤100mVp-p |
|
|
SETUP, RISE TIME |
1300ms, 40ms/230VAC 2200ms, 16ms/115VAC(at full load) |
|
|
INPUT |
VOLTAGE RANGE |
96-264V |
|
AC CURRENT (Typ.) |
0.5A/115VAC |
|
|
FREQUENCY RANGE |
47-63Hz |
|
|
EFFICIENCY (Typ.) |
84% |
|
|
LEAKAGE CURRENT |
<2mA/ 240VAC |
|
|
INRUSH CURRENT (Typ.) |
20A/115VAC |
|
|
30A/230VAC |
||
|
PROTECTION |
OVERLOAD(Note.7) |
110 ~ 140% rated output power |
|
Protection type: Hiccup mode, recovers automatically after fault condition is removed |
||
|
ENVIRONMENT |
WORKING TEMP. |
-25-40℃(Refer to "Derating Curve") |
|
WORKING HUMIDITY |
20%-90% RH non-condensing |
|
|
STORAGE TEMP, HUMIDITY |
-40-85℃ 10%---95% RH |
|
|
TEMP. COEFFICIENT |
± 0.03%/ 50℃ (0 ~ 50℃) |
|
|
VIBRATION |
10 ~ 500Hz, 5G 10min./1cycle, 60min. each along X, Y, Z axes |
|
|
SAFETY |
SAFETY STANDARDS |
IEC/EN/UL/CSA 60950 GB4943 |
|
WITHSTAND VOLTAGE |
I/P-O/P:3KVAC, I/P-FG:2KVAC, O/P-FG0.5KVAC |
|
|
EMC EMISSION |
Compliance to BSMI CNS13438, EAC TP TC 020 |
|
|
EMC IMMUNITY |
Compliance to EAC TPTC 020 |
|
|
ISOLATION RESISTANCE |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC / 25℃ / 70% RH |
|
|
OTHERS |
MTBF |
≥327.9K hrs min. MIL-HDBK-217F（25℃) |
|
DIMENSION (L*W*H mm) |
93*46.5*39.5mm (L*W*H) |
|
|
PACKING |
100pcs/16.5Kg/0.065CUFT |
|
|
PRODUCT WEIGHT |
0.163KGS |
|
